Custom PCB Assembly Smart Meter PCBA Manufacture SWR Meter&PWR Power Meter PCB assembly

1. Features

1. One Stop OEM Service, Made in Shenzhen of China

2. Manufactured by Gerber File and BOM List from Customer

3. FR4 Material, Meet 94V0 standard

4. SMT, DIP technology suport

5. Lead Free HASL, Environmental Protection

6. UL, CE, ROHS Compliant

7. Shipping By DHL,UPS, TNT, EMS or Customer requirement

2. PCB Technical capability

Certifications:

ISO9001 / ISO14001 / ISO45001 (Military) / TS16949 (Automotive) / RoHS / UL

Customized PCB assembly process

PCB Design and Fabrication:
Collaborate with PCB design engineers to create schematics and layouts for custom PCBs.
Complete PCB design, including component placement, trace routing, and any special requirements.
Send design files to PCB manufacturer for fabrication.
Receive the bare PCB from the manufacturer and check for any defects.

Component purchasing:
Determine the required electronic components such as ICs, resistors, capacitors, and connectors.
Purchase necessary components from an authorized distributor or direct from the manufacturer.
Ensure components are compatible with the PCB design and meet the specifications of the project.

PCB Assembly:
Prepare the PCB for assembly by cleaning the surface and applying solder paste to component pads.
Use automated pick and place machines to place components accurately on the PCB.
Reflowing the solder paste in a controlled environment, such as a reflow oven, creates component connections.
Perform visual and electrical inspection of assembled PCBs to ensure proper component placement and solder joints.

Dedicated assembly process (if necessary):
Depending on the PCB design and application, additional assembly processes may be required, such as:
Through-hole component insertion and soldering
Ball Grid Array (BGA) or Chip Scale Package (CSP) component connections
Conformal coating or potting for environmental protection
Heat sink or thermal management component installation

Testing and Quality Assurance:
Perform various tests to verify functionality and reliability of custom PCBs such as:
Electrical testing (e.g. continuity, resistance, voltage and current measurements)
Functional testing to ensure PCB meets design specifications
Environmental testing (e.g. temperature, humidity, vibration) (if necessary)
Document test results and any problems encountered during assembly.

Final assembly and packaging:
Integrate custom PCB into final product or system (if applicable).
Pack PCBs or complete assemblies for safe shipping and delivery to customers.
Provide any necessary documentation such as assembly instructions, schematics, and test reports.

Throughout the custom PCB assembly process, manufacturers should maintain strict quality control procedures, adhere to industry standards, and ensure traceability of all components and processes.

2. PCB Pictures

In the year of 2024, SHENZHEN KAIZUO ELECTRONIC TECHNOLOGY CO., LTD (KAZ CIRCUIT) has joined Kingsum group (www.kingsumpcba.com), to seek for a larger market share from PCB manufacturing, component sourcing, pcb assembly, and box build assembly with better price and lead time.

Founded in 2007, KaiZuo Electronic (hereinafter referred to as KAZ) is a professional & high quality provider of Electronic Manufacturer Service (EMS) from China. With about 300 experienced employees, KAZ can provide customers with one stop services including PCB manufacturing, Components Sourcing, PCB Assembly, Cable Assembly, Box Building, IC Programming, Functional and Aging Testing. Certified with ISO9001, UL, RoHS, TS16949.

Equipped with 5 high-speed SMT, automatic printing machine (DSP1008), MIRAE MX200/MIRAE MX400 high-speed production line, YAMAHA equipment (YS24/YG12F...), reflow soldering (NS-1000), AOI testing equipment (JTA-320-M), X-Ray inspection equipment (Nikon AX7200), 2 DIP production lines and Nitto wave soldering.

After focusing on the electronic manufacturer services for 13+ years, KAZ has established long-term cooperated & satisfied customers all over the world. Mainly from North America, European, Asia and Australia. Application fields including industrial control, IT/Networking, IoT, security, automotive, power electronics, consumer electronics, lighting, etc.
